| 类型 | 其它 |
|---|---|
| 品牌 | 克莱默kramer |
| 型号 | VS-121HCA12x1 |
The VS-121HCA is a high-performance switcher for stereo audio and S/PDIF audio signals. The unit consists of two independent 12x1 switchers that switch simultaneously without any analog to digital or digital transcoding.
- 单独使用或者与VS-121HC 配合使用输入 - 12 S/PDIF (RCA connectors) and 12 balanced stereo audio (terminal blocks).
- 输出- 1 S/PDIF (RCA connector) and 1 balanced stereo audio (terminal blocks).
- 前面板锁定灵活控制- Front panel, RS-232 (K-Router™ Windows®-based software is included), Ethernet & IR remote (included)
- **用电源- 100-240V AC
- 标准19英尺机架尺寸- 1U. Rack "ears" included
- 输入 - 12 unbalanced stereo on 6-pin terminal block connectors; 12 S/PDIF on RCA connectors
- 输出 - 1 unbalanced stereo on 6-pin terminal block connector; 1 S/PDIF on RCA connector
- **大输出电平 - 6Vpp
- 带宽 (-3dB): - 46kHz
- 信噪比: - 67dB @1kHz
- 串扰(all hostile): - -75dB @1kHz
